PG200R THRU PG208R
GLASS PASSIVATED JUNCTION FAST SWITCHING RECTIFIER
VOLTAGE - 50 to 800 Volts
FEATURES
l
Plastic package has Underwriters Laboratory
Flammability Classification 94V-O Utilizing
l
l
l
l
Flame Retardant Epoxy Molding Compound
Glass passivated junction in DO-15 package
2.0 ampere operation at T
A
=55
壟J
with no thermal runaway
Exceeds environmental standards of MIL-S-19500/228
Fast switching for high efficiency
CURRENT - 2.0 Amperes
DO-15
MECHANICAL DATA
Case: Molded plastic, DO-15
Terminals: axial leads, solderable per MIL-STD-202,
Method 208
Polarity: Band denotes cathode
Mounting Position: Any
Weight: 0.015 ounce, 0.4 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
壟J
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
PG200R PG201R PG202R PG204R PG206R PG208R
UNITS
Peak Reverse Voltage, Repetitive; V
RM
Maximum RMS Voltage
DC Reverse Voltage; V
R
Average Forward Current, IO @ T
A
=55
壟J
3.8鈥漧ead
length 60 Hz, resistive or inductive load
Peak Forward Surge Current, I
FM
(surge) 8.3msec.
single half sine wave superimposed on rated
load(JECEC method)
Maximum Forward Voltage V
F
@2.0A, 25
壟J
Maximum Reverse Current, @Rated T
a
=25
壟J
Reverse Voltage T
a
=100
壟J
Typical Junction capacitance (Note 1) CJ
Typical Thermal Resistance (Note 2) R
攏KJA
Reverse Recovery Time
I
F
=.5A, I
R
=1A, Irr=.25A
Operating and Storage Temperature Range
50
35
50
100
70
100
200
140
200
2.0
70
400
280
400
600
420
600
800
560
800
V
V
V
A
A
1.3
5.0
2000
35
22
150
150
150
150
250
500
V
攏g
A
P
F
壟J
/W
ns
壟J
-55 to +150
NOTES:
1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC
2. Thermal resistance from junction to ambient at 0.375"(9.5mm) lead length P.C.B. mounted
