UltraCMOS鈩?/div>
prescaler with a fixed divide ratio of 2. Its operating frequency
range is 1500 MHz to 3500 MHz. The PE9301 operates on a
nominal 3 V supply and draws only 13 mA. It is packaged in a
small 8-lead CSOIC and is ideal for Space microwave PLL
synthesis solutions.
The PE9301 is manufactured on Peregrine鈥檚 UltraCMOS鈩?/div>
process, a patented variation of silicon-on-insulator (SOI)
technology on a sapphire substrate, offering the performance
of GaAs with the economy and integration of conventional
CMOS.
3500 MHz Low Power UltraCMOS鈩?/div>
Divide-by-2 Prescaler
Rad-hard for Space Applications
Features
鈥?/div>
High-frequency operation: 1500 MHz
to 3500 MHz
鈥?/div>
Fixed divide ratio of 2
鈥?/div>
Low-power operation: 13 mA typical
@ 3 V across frequency
鈥?/div>
Small package: 8-lead SOIC
鈥?/div>
Low Cost
Figure 1. Functional Diagram
Figure 2. Package Type
8-lead CSOIC
D
Q
QB
DRIVER
OUTPUT BUFFER
OUT
IN
PREAMP
CLK
DEC
INB
DEC
CLKB
OFF-CHIP
BYPASS
Table 1. Electrical Specifications @ +25 擄C
(Z
S
= Z
L
= 50
鈩?
Parameter
Supply Voltage
Supply Current
Input Frequency (F
IN
)
Input Power (P
IN
)
Output Power
P
IN
= -5 dBm min.
F
IN
= 1.5 to 3.5 GHz
1.5
-5
-10
Conditions
Minimum
2.85
Typical
3.0
13
Maximum
3.15
15
3.5
+5
Units
V
mA
GHz
dBm
dBm
Document No. 70-0039-02
鈹?/div>
www.psemi.com
漏2003-2006 Peregrine Semiconductor Corp. All rights reserved.
Page 1 of 7
