Product Specification
PE42742
Product Description
The PE42742 is an SPDT
UltraCMOS鈩?/div>
Switch designed for
Broadband applications such as CATV, DTV, Multi-Tuner
DVR (Digital Video Recorder), Set-top Box, PCTV and Game
Boxes. It meets FCC 15.115 spec of 80 dB isolation @ 216
MHz and offers high isolation and low insertion loss in both a
powered and a unique unpowered default state. The
PE42742 covers a broad frequency range from near DC to
beyond 2200 MHz with a single positive supply and CMOS
control. It provides a smaller, cost effective, more reliable
and manufacturable alternative to mechanical relays in set-
top box applications.
The PE42742 is manufactured on Peregrine鈥檚 UltraCMOS鈩?/div>
process, a patented variation of silicon-on-insulator (SOI)
technology on a sapphire substrate, offering the performance
of GaAs with the economy and integration of conventional
CMOS.
75
鈩?/div>
Terminated - 2200 MHz SPDT
CATV UltraCMOS鈩?Switch
Featuring Unpowered Operation
Features
鈥?/div>
Meets FCC 15.115 spec of 80 dB
isolation @ 216 MHz
鈥?/div>
Unpowered operational state
鈥?/div>
2000 V HBM ESD tolerance, RF Pins
鈥?/div>
CTB performance of 90 dBc
鈥?/div>
High isolation: 63 dB at 1000 MHz
鈥?/div>
Low insertion loss: typically 0.5 dB at
5 MHz, 0.8 dB at 1000 MHz
鈥?/div>
CMOS single-pin control with logic
select
鈥?/div>
Single +3 volt supply operation
鈥?/div>
Low current consumption: 8
碌A(chǔ)
Figure 1. Functional Diagram
RFC
Figure 2. Package Type
4x4 mm 20-lead QFN
RF1
RF2
75
CMOS
Control
Driver
75
C1
C2
Document No. 70-0203-03
鈹?/div>
www.psemi.com
漏2006 Peregrine Semiconductor Corp. All rights reserved.
Page 1 of 11
