Product Specification
PE4210
Product Description
The PE4210 UltraCMOS鈩?RF Switch is designed to cover a
broad range of applications from near DC to 3000 MHz. This
single-supply switch integrates on-board CMOS control logic
driven by a simple, single-pin CMOS or TTL compatible control
input. Using a nominal +3-volt power supply, a typical input
1 dB compression point of +14 dBm can be achieved. The
PE4210 also exhibits input-output isolation of better than 35 dB
at 1000 MHz and is offered in a small 8-lead MSOP package.
The PE4210 UltraCMOS鈩?RF Switch is manufactured in
Peregrine鈥檚 patented Ultra Thin Silicon (UTSi廬) CMOS
process, offering the performance of GaAs with the economy
and integration of conventional CMOS.
Figure 1. Functional Diagram
RFC
SPDT UltraCMOS鈩?RF Switch
DC - 3000 MHz
Features
鈥?/div>
Single 3-volt power supply
鈥?/div>
Low Insertion loss: 0.30 dB at 1000 MHz,
0.45 dB at 2000 MHz
鈥?/div>
High isolation of 35 dB at 1000 MHz,
25 dB at 2000 MHz
鈥?/div>
Typical input 1 dB compression point of
+14.5 dBm
鈥?/div>
Single-pin CMOS or TTL logic control
鈥?/div>
Packaged in a small 8-lead MSOP
Figure 2. Package Type
8-lead MSOP
RF1
RF2
CMOS
Control
Driver
CTRL
Table 1. Electrical Specifications @ +25 擄C, V
DD
= 3 V
(Z
S
= Z
L
= 50
鈩?
Parameter
Operating Frequency
1
Insertion Loss
Isolation 鈥?RFC to RF1/RF2
Isolation 鈥?RF1 to RF2
Return Loss
鈥極N鈥?Switching Time
鈥極FF鈥?Switching Time
Video Feedthrough
2
Input 1 dB Compression
Input IP3
Notes:
2000 MHz
2000 MHz, 5 dBm
1. Device linearity will begin to degrade below 10 MHz.
2. The DC transient at the output of any port of the switch when the control voltage is switched from Low to High or High to Low
in a 50
鈩?/div>
test set-up, measured with 1ns risetime pulses and 500 MHz bandwidth.
Document No. 70-0037-05
鈹?/div>
www.psemi.com
漏2005 Peregrine Semiconductor Corp. All rights reserved.
Page 1 of 7
13
30
1000 MHz
2000 MHz
1000 MHz
2000 MHz
1000 MHz
2000 MHz
1000 MHz
2000 MHz
CTRL to 0.1 dB final value, 2 GHz
CTRL to 25 dB isolation, 2 GHz
34.5
24.5
36.5
25.5
22.5
15
Conditions
Minimum
DC
Typical
0.30
0.45
35.5
25
37.5
26.5
24.5
16
200
90
2.5
14.5
33.5
Maximum
3000
0.40
0.60
Units
MHz
dB
dB
dB
dB
dB
dB
dB
dB
ns
ns
mV
pp
dBm
dBm
