Four-Way 0擄 Power Splitter
Combiner 0.81鈥?.96 GHz
PD4W09-59
Features
s
Low Cost
s
Low Profile
s
Available in Small MSOP-8 Package
s
Tape & Reel
Description
The PD4W09-59 is a monolithic four-way in-phase hybrid
junction tuned for the 0.81鈥?.96 GHz band. It offers low
loss, high isolation, good input/output matching and
exceptional phase/amplitude balance. It is available in the
MSOP-8 leaded surface mount package.
Electrical Specifications at 25擄C
Parameter
Frequency
Insertion Loss Less 6 dB Split
Isolation
Input VSWR
Output VSWR
Amplitude Balance
Phase Balance
20
Min.
0.81
1.3
23
1.2:1
1.2:1
鹵0.4
鹵6
1.5:1
1.5:1
鹵0.6
鹵8
dB
Deg.
Typ.
Max.
0.96
1.5
Unit
GHz
dB
dB
Pin Out
Block Diagram
4W09
Port 1
IN/SUM
GND
Port 4
Port 2
GND
GND
Port 3
Port 1
Port 2
IN/SUM
Port 3
Port 4
Alpha Industries, Inc.
[781] 935-5150
鈥?/div>
Fax
[617] 824-4579
鈥?/div>
Email
sales@alphaind.com
鈥?/div>
www.alphaind.com
Specifications subject to change without notice. 3/99A
1
2
3
4
8
7
6
5
1
1
2
3
