PCA1.2005.5S Datasheet

  • PCA1.2005.5S

  • Platinum-chip temperature sensors(127.13 k)

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M. K. JUCHHEIM GmbH & Co
Delivery address:Mackenrodtstra脽e 14,
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone:
+49 661 60 03-0
Fax:
+49 661 60 03-6 07
E-mail:
mail@jumo.net
Internet:
www.jumo.de
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2TT, UK
Phone: +44 12 79 63 55 33
Fax:
+44 12 79 63 52 62
E-mail: sales@jumo.co.uk
JUMO PROCESS CONTROL INC.
885 Fox Chase, Suite 103
Coatesville PA 19320, USA
Phone: 610-380-8002
1-800-554-JUMO
Fax:
610-380-8009
E-mail: info@JumoUSA.com
Internet: www.JumoUSA.com
Data Sheet 90.6121
Page 1/4
Platinum-chip temperature sensors
to EN 60 751
鈻?/div>
for temperatures from -50 to +600擄C
鈻?/div>
with nominal values of 100, 500 and 1000
鈩?/div>
鈻?/div>
standard nominal values and tolerances
鈻?/div>
small sizes, from 2mm x 2.5mm
鈻?/div>
special selection available
Small dimensions, fast response, high-resistance nominal values and considerable insen-
sitivity to shock and vibration when fixed, as well as high measurement accuracy and
long-term stability - these are the advantages of this cost-effective style. Applications in-
clude many tasks in measurement and control engineering.
Type designation
P
C
A
1.
20
10
.1
.5
.10
L
S
M
H
platinum resistance material to EN 60 751
chip style
connecting wires
1 measurement winding
width W in 0.1mm (2.0mm)
length L in mm (10mm)
nominal value 100
鈩?/div>
at 0擄C
nominal value 500
鈩?/div>
at 0擄C
nominal value 1000
鈩?/div>
at 0擄C
temperature range from -50 to +250擄C
temperature range from -50 to +400擄C
temperature range from -50 to +550擄C
temperature range from -50 to +600擄C
Temperature sensors up to 250擄C with connecting wires
and nominal values of 100, 500 and 1000鈩?at 0擄C
Type
Sensor body
W L
H S
Connecting wires
Sales No.
Dim.
L1 R
L
Material
90/00047580
90/00063260
90/00044789
90/00063261
90/00048147
90/00062565
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
Tolerance class B
鹵
(0.3 + 0.005 鈥?Itl)擄C, alpha = 3.850 鈥?10
-3
擄C
-1
PCA 1.2003.1 L 2.0 2.5 1.3 0.6 脴 0.25
15 0.8 Ag/Pd
PCA 1.2005.1 L 2.0 5
1.3 0.6 0.2 x 0.3 10 0.3 Ag
PCA 1.2010.1 L 2.0 10 1.3 0.6 0.2 x 0.3 10 0.3 Ag
PCA 1.2005.5 L 2.0 5
1.3 0.6 0.2 x 0.3 10 0.3 Ag
PCA 1.2010.5 L 2.0 10 1.3 0.6 0.2 x 0.3 10 0.3 Ag
PCA 1.2010.10 L 2.0 10 1.3 0.6 0.2 x 0.3 10 0,3 Ag
Note:
The specified nominal value refers to the standard length L1 of the connecting wires, with
the measurement point 2mm from the open end of the wires. A change in the wire length
may result in appreciable changes in resistance.
R
L
= longitudinal resistance of a single connecting wire at 0擄C in m
鈩?/div>
/mm.
Platinum-chip temperature sensors must not be used unprotected in a humid environment
or for direct measurement in liquids.
All dimensions in mm.
鈼?/div>
Available from stock.
Item 1
06.01/00311575
