PC87414 Datasheet

  • PC87414

  • LPC ServerI/O for Servers and Workstations

  • 257頁

  • NSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PC87413, PC87414, PC87416, PC87417 LPC ServerI/O for Servers and Workstations
July 2003
Revision 1.2
PC87413, PC87414, PC87416, PC87417
LPC ServerI/O for Servers and Workstations
General Description
The National Semiconductor
廬
PC8741x family of LPC Serv-
erI/O devices (鈥淧C8741x鈥? comprises highly integrated Ad-
vanced I/O products. The PC8741x is targeted for a wide
range of servers and workstations that use the Low Pin Count
(LPC) bus for the host interface and the serial ACCESS.bus
or SMBus
廬
for the embedded controller interface.
The PC8741x features an X-Bus extension for read and write
operations over the X-Bus for both LPC and ACCESS.bus
cycles. Boot Flash and I/O devices can be accessed over this
X-Bus.
Embedded controllers can access the PC8741x and its X-Bus
via the ACCESS.bus or SMBus serial interface when V
SB
exists, regardless of the LPC bus state. Some of the
PC8741x logical devices can be disabled, or their pins can be
floated, under control of the V
SB
-powered serial bus.
The PC8741x provides a V
SB
-powered high-frequency clock
for on-chip peripherals and for other V
SB
-powered platform
components.
The PC8741x鈥檚 extended wake-up support complements the
chipset鈥檚 ACPI controller and the platform embedded control-
lers. The PC8741x can monitor the Power and Sleep buttons
and control the power supply of simple platforms that lack an
embedded controller. The System Wake-Up Control (SWC)
module is powered by V
SB
and V
BAT
power supplies. It sup-
ports flexible wake-up and power-off request mechanisms in
any sleep state. It features Main and Standby power-on
elapsed-time counters.
The PC8741x also incorporates a Floppy Disk Controller
(FDC), two serial ports (UARTs), a Keyboard and Mouse
Controller (KBC), a Real-Time Clock (RTC), a fully compliant
IEEE 1284 Parallel Port, General-Purpose Input/Output
(GPIO) for a total of 51 ports and an Interrupt Serializer for
Parallel IRQs.
Outstanding Features
s
s
s
s
s
s
s
s
s
LPC Interface, based on Intel鈥檚
LPC Interface Speci鏗?
cation, Revision 1.0, September 29th, 1997
V
SB
-powered access to modules through ACCESS.bus
or SMBus (PC87413
and PC87417)
X-Bus Extension for memory and I/O (PC87416
and
PC87417)
PC01 Revision 0.5 and ACPI Revision 1.0b compliant
ServerI/O modules: Parallel Port, FDC, two Serial Ports
(UARTs) and a Keyboard and Mouse Controller (KBC)
Y2K-compliant RTC with 242 bytes of RAM
51 GPIO ports with a variety of wake-up events
Extremely low current consumption in Battery Backup mode
128-pin PQFP package
Block Diagram
PC87417
(See page 5 for other PC8741x diagrams.)
Serial
Serial
Interface Interface
ServerI/O
Clock
V
DD
Serial
Port 1
Serial
Port 2
Parallel Port
Interface
IEEE 1284
Parallel Port
Floppy Drive
Interface
Floppy Disk
Controller
LPC Serial
Keyboard Mouse
Interface Interface Interface IRQ
Keyboard &
Mouse Controller
LPC Bus
Interface
Device
Configuration
V
BAT
V
SB
System
Wake-Up Control
Power
On
Timers
RTC
Internal Clocks
Clock
Generator
GPIO
Ports
X-Bus
Extension
ACCESS.bus
Interface
Wake-Up Power SCI &
Events Control SMI
Low-F High-F
32.768 KHz Clock Clock
X-Bus XIRQ
I/O
Interface
Ports
Clock Serial
Data
National Semiconductor and TRI-STATE are registered trademarks of National Semiconductor Corporation. All other
brand or product names are trademarks or registered trademarks of their respective holders.
漏 2003 National Semiconductor Corporation
www.national.com
