SELF-LEADED SMT
COMMON MODE CHOKE
Solutions based on impedance, size and
current
Designed for DC/DC converters
Wide variety of inductor sizes and current
ratings available
Dielectric strength: 500 V
RMS
Electrical Specifications @ 25擄C 鈥?Operating Temperature -40擄C to +120擄C
Part
Number
RatedCurrent
For 55擄C Rise
(Amps)
Inductance
(mH 鹵35%)
DCR (MAX)
(m鈩?
Impedance
Curve
(see # below)
Package
Weight
(Grams)
Quantity
In Tube
Quantity
In Reel
P0354
P0473
P0351
P0420
P0421
P0422
P0353
P0527
P0429
P0469
P0502
1.22
1.63
2.80
3.30
3.30
4.70
5.60
7.20
9.70
11.6
14.0
1.170
0.884
1.470
1.320
0.225
0.768
0.590
0.530
0.809
0.630
0.473
200
110
80
60
60
40
20
15
14
10
8
1
2
3
4
5
6
7
8
6
7
9
Polecat
Polecat
LCCI-50
LCCI-50
LCCI-50
LCCI-50
LCCI-50
HCCI-68
Big Foot
Big Foot
Big Foot
1.4
1.5
4.3
4.6
4.7
4.9
5.2
7.7
13.5
14.3
14.8
40
40
30
30
30
30
30
20
15
15
15
500
500
200
200
200
200
200
100
75
75
75
NOTE:
Add suffix
"T"
to part number for tape and reel package (i.e. P0354T).
Impedance Curves
15K
7.5K
6
12K
Impedance
(鈩?
6.0K
4
Impedance
(鈩?
3
9K
1
2
6K
5
4.5K
9
3.0K
7
8
3K
1.5K
0
100 KHz
1 MHz
10 MHz
100 MHz
0
100 KHz
1 MHz
10 MHz
100 MHz
Frequency
Frequency
US 858 674 8100
鈥?/div>
UK 44 1483 401 700
鈥?/div>
France 33 3 84 35 04 04
鈥?/div>
Singapore 65 287 8998
鈥?/div>
Taiwan 886 2 2698 0228
鈥?/div>
Hong Kong 852 2788 6588
鈥?/div>
http://www.pulseeng.com
PC500.B (5/02)
54
