PC355NT

Features

1. High current transfer ratio

( CTR : MIN. 600% at I

= 1mA, V

= 2V)

2. Opaque type, mini-flat package

PC355NT

( 1-channel )

3. Subminirature type

( The volume is smaller than that of our

conventional DIP type by as far as 30%)

4. Isolation voltage between input and output

PC355NT

鈥⑩€⑩€iso : 3 750V

rms

5. Recognized by UL (NO. E64380)

Mini-Flat Package,

High Sensitivity Photocoupler

Outline Dimensions

PC355NT

2.54

鹵

0.25

355

Anode

mark

0.4

鹵

0.1

鹵

0.1

2.6

鹵

0.2

C0.4

Input side

5.3

鹵

0.3

4.4

鹵

0.2

Internal connection

diagram

( Unit : mm )

Anode

Cathode

Emitter

Collector

3.6

鹵

0.3

0.5

0.4

0.2

7.0

0.2

0.7

6藲

Package Specifications

Model No.

PC355NT

Taping specifications

Taping reel diameter 178mm (750pcs.)

Applications

1. Hybrid substrates that require high density

mounting.

2. Programmable controllers

鈥?/div>

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that occur in equipment using any of SHARP's devices, shown in catalogs,

data books, etc. Contact SHARP in order to obtain the latest version of the device specification sheets before using any SHARP's device.鈥?/div>

0.2

鹵

0.05

標準包裝
3,000
類別
隔離器
家庭
光隔離器 - 晶體管，光電輸出
系列
-
通道數
1
輸入類型
DC
電壓 - 隔離
3750Vrms
電流傳輸比（最小值）
600% @ 1mA
電流傳輸比（最大）
-
輸出電壓
35V
電流 - 輸出 / 通道
80mA
電流 - DC 正向(If)
50mA
Vce飽和（最大）
1V
輸出類型
達林頓晶體管
安裝類型
表面貼裝
封裝/外殼
4-SMD
包裝
帶卷 (TR)
