Mechanical Data
路
路
路
路
路
路
路
路
路
路
Case: PBPC-3
Case Material: Molded Plastic. UL Flammability
Classification 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Plated Leads Solderable per MIL-STD-202,
Method 208
Polarity: Marked on Body
Mounting: Through Hole for Screw
Mounting Torque: 5.0 Inch-pounds Maximum
Ordering Information: See Last Page
Marking: Type Number
Weight: 3.8 grams (approximate)
A
E
AC
A
B
C
D
E
-
C
0.76
脝
Typical
D
G
Hole for screw
3.60
4.00
11.30
B
A
H
10.30
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
(Note 1) @ T
C
= 50擄C
(Note 2) @ T
C
= 50擄C
Symbol PBPC
301
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
R
I
2
t
C
T
R
qJC
T
j,
T
STG
50
35
@ T
A
= 25擄C unless otherwise specified
PBPC
302
100
70
PBPC
303
200
140
PBPC
304
400
280
3.0
2.0
50
1.2
10
1.0
10
55
25
-65 to +125
PBPC
305
600
420
PBPC
306
800
560
PBPC
307
1000
700
Unit
V
V
A
A
V
碌A
mA
A
2
s
pF
擄C/W
擄C
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
Forward Voltage (per element)
@ I
F
= 1.5A
Peak Reverse Current
@ T
C
= 25擄C
at Rated DC Blocking Voltage (per element) @ T
C
= 100擄C
I
2
t Rating for Fusing (t<8.3ms) (Note 3)
Typical Total Capacitance (Note 4)
Typical Thermal Resistance Junction to Case (per element)
Operating and Storage Temperature Range
Notes:
1.
2.
3.
4.
Mounted on metal chassis.
Mounted on PC board FR-4 material.
Non-repetitive, for t > 1ms and < 8.3ms.
Per element, measured at 1.0 MHz and applied reverse voltage of 4.0V DC.
DS21345 Rev. 6 - 2
1 of 3
www.diodes.com
PBPC301-PBPC307
