50-870 MHz
High Dynamic Range Amplifier
March 2007 - Rev 13-Mar-07
CMM6003-SC (-BD)
Functional Block Diagram
Ground
4
Features
50 to 870 MHz Frequency Range
+41 dBm Output IP3
1.6 dB Noise Figure (@ 450 MHz)
17 dB Gain
22 dBm P1dB
SOT-89 SMT Package
Single Power Supply
+3V to +5V Voltage Rail
1
Input
2
3
Ground Output
Bias
Description
The CMM6003-SC is a high dynamic range amplifier designed
for applications operating within the 50 MHz to 870 MHz
frequency range. It is an ideal solution for transmit and receive
functions where high linearity is required.
The amplifier has the flexibility of being optimized for a
number of wireless applications. The combination of gain
flatness, bandwidth, low NF and high IP3 at the same bias
point make it an ideal transmit or receive solution when used
in intermediate frequency applications.
Absolute Maximum Ratings
Supply Voltage
RF Input Power*
Storage Temperature
Junction Temperature
Operating Temperature
Thermal Resistance
+6.0 V
+10 dBm
-55潞C to 150潞C
150潞C
-40潞C to +85潞C
59潞 C/W
Operation of this device above any of these parameters may cause damage.
*Operation with more than 10 dBm of input power may cause 2 dB
degradation in OIP3 performance.
The CMM6003-SC is packaged in a low-cost space efficient,
surface mount SOT-89 package which provides excellent
electrical stability and low thermal resistance. All devices are
100% RF (at 800 MHz) and DC tested.
Electrical Characteristics
Parameter
Condition
Unless otherwise specified, the following specifications are guaranteed at room temperature
in a Mimix test fixture.
Min
Typ
Max
Units
Typical Parameters
Parameter
Typical
Units
F requency R ange
Gain
Input Return Loss
O utput I P3
Noise Figure
Noise Figure
Output P1dB
Operating Current Range
Supply Voltage
Externally matched
Externally matched
@ 50 MHz
@ 800 MHz
50
15
120
800
17
-11
+41
3.3
1.9
22
150
5. 0
870
18
180
MH z
dB
dB
dB m
dB
dB
dBm
mA
V
Frequency Range
Gain
Input Return Loss
Output Return Loss
Output IP3
Output P1dB
Noise Figure
450
17.2
-12.0
-16
+39
23.6
1.6
800
16.5
-11.5
-14
+41
23.7
1.9
870
16.25
-10.5
-13
+37
23.8
2.0
MHz
dB
dB
dB
dBm
dBm
dB
Notes:
1. Typical values reflect performance in recommended application circuit.
Notes:
1. T = 25擄C, Vdd = 5.0, Frequency = 800 MHz, 50 Ohm system
2. OIP3 measured with two tones at output power of 5 dBm/tone separated by 10 MHz.
Mimix Broadband, Inc., 10795 Rockley Rd., Houston, Texas 77099
Tel: 281.988.4600 Fax: 281.988.4615 mimixbroadband.com
Page 1 of 5
Characteristic Data and Specifications are subject to change without notice.
漏2007
Mimix Broadband, Inc.
Export of this item may require appropriate export licensing from the U.S. Government. In purchasing these parts, U.S. Domestic customers accept
their obligation to be compliant with U.S. Export Laws.
