PA9122AP

SINGLE PHASE POWER/ENERGY ADAPTOR WITH

64 SEGMENT LCD AND SERIAL INTERFACE

FEATURES

n

sames

SA9122APA APPLICATION NOTE

Enables the demonstration of the

SA9122APA device using a

PM9103AP module

Pulse rate selectable via jumper leads

n

n

n

Operates over a wide temperature range

Protected against ESD

Meets the accuracy requirements for

Class 1 AC Watt hour meters

n

DESCRIPTION

The PA9122AP demonstration adaptor connects into the PM9103AP metering module.

In this configuration the PA9122AP allows evaluation of the SA9122EPA device.

It is recommended that this Application Note be read in conjunction with the PM9103AP

Application Note.

The PA9122AP adaptor comes complete with an LCD, the SA9122EPA device as well

as demonstration software.

1/6

7191

PDS038-SA9122-001

Rev. A

28-01-97
