UNISONIC TECHNOLOGIES CO., LTD

PA5417

HIGH-OUTPUT DUAL POWER

AMPLIFIER

DESCRIPTION

The UTC

PA5417

is a dual power amplifier of 6~15V-compatible

for radio cassette/Mini compo players use. It is developed to equip

with standby switching functions for excellent total harmonic

distortion and other basic characteristics.

LINEAR INTEGRATED CIRCUIT

HZIP-15A

FEATURES

* Operating power supply voltage range from 6V to 15V.

* High output.

- P

OUT

= 2.8W (V

CC

= 9V, R

L

=3鈩? THD = 10%)

- P

OUT

= 5.0W (V

CC

= 12V, R

L

=3鈩? THD = 10%)

* Excellent audio quality

- THD = 0.1% (f = 1kHz, P

OUT

= 0.5W)

- eN = 0.3mVrms (Rg = 10k鈩?

- RR = 55dB (f

RR

= 100Hz)

* Switching noise (鈥減op鈥?noise) generated when the power is

switched on and off is small.

* Ripple mixing when motor starts has been prevented.

* Built-in thermal shutdown circuit.

* Built-in standby switch that output is not influenced.

* Soft clipping.

*Pb-free plating product number: PA5417L

ORDERING INFORMATION

Order Number

Normal

Lead Free Plating

PA5417-J15-A-T

PA5417L-J15-A-T

Package

HZIP-15A

Packing

Tube

PA5417L-J15-A-T

(1) Packing Type

(2) Package Type

(3) Lead Plating

(1) T: Tube

(2) J15-A: HZIP-15A

(3) L: Lead Free Plating, Blank: Pb/Sn

www.unisonic.com.tw

Copyright 漏 2005 Unisonic Technologies Co., Ltd

1 of 7

QW-R107-049,B
