P89LPC938 Datasheet

  • P89LPC938

  • 8-bit microcontroller with accelerated two-clock 80C51 core ...

  • 68頁

  • PHILIPS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

P89LPC938
8-bit microcontroller with accelerated two-clock 80C51 core
8 kB 3 V byte-erasable Flash with 10-bit A/D converter
Rev. 01 鈥?25 February 2005
Product data sheet
1. General description
The P89LPC938 is a single-chip microcontroller, available in low cost packages, based on
a high performance processor architecture that executes instructions in two to four clocks,
six times the rate of standard 80C51 devices. Many system-level functions have been
incorporated into the P89LPC938 in order to reduce component count, board space, and
system cost.
2. Features
2.1 Principal features
s
8 kB byte-erasable Flash code memory organized into 1 kB sectors and 64-byte
pages. Single-byte erasing allows any byte(s) to be used as non-volatile data storage.
s
256-byte RAM data memory and a 512-byte auxiliary on-chip RAM.
s
512-byte customer Data EEPROM on chip allows serialization of devices, storage of
set-up parameters, etc.
s
8-input multiplexed 10-bit A/D converter. Two analog comparators with selectable
inputs and reference source.
s
Two 16-bit counter/timers (each may be con鏗乬ured to toggle a port output upon timer
over鏗俹w or to become a PWM output) and a 23-bit system timer that can also be used
as a RTC.
s
Enhanced UART with fractional baud rate generator, break detect, framing error
detection, and automatic address detection; 400 kHz byte-wide I
2
C-bus
communication port and SPI communication port.
s
CCU provides PWM, input capture, and output compare functions.
s
High-accuracy internal RC oscillator option allows operation without external oscillator
components. The RC oscillator option is selectable and 鏗乶e tunable.
s
2.4 V to 3.6 V V
DD
operating range. I/O pins are 5 V tolerant (may be pulled up or
driven to 5.5 V).
s
28-pin TSSOP, PLCC, and HVQFN packages with 23 I/O pins minimum and up to 26
I/O pins while using on-chip oscillator and reset options.
