P6KE6.8CA Series

600 Watt Peak Power

Surmetict-40 Zener Transient

Voltage Suppressors

Bidirectional*

The P6KE6.8CA series is designed to protect voltage sensitive

components from high voltage, high energy transients. They have

excellent clamping capability, high surge capability, low zener

impedance and fast response time. These devices are

ON Semiconductor鈥檚 exclusive, cost-effective, highly reliable

Surmetic axial leaded package and is ideally-suited for use in

communication systems, numerical controls, process controls,

medical equipment, business machines, power supplies and many

other industrial/consumer applications.

Specification Features:

http://onsemi.com

鈥?/div>

Working Peak Reverse Voltage Range 鈥?5.8 to 171 V

Peak Power 鈥?600 Watts @ 1 ms

ESD Rating of class 3 (>16 KV) per Human Body Model

Maximum Clamp Voltage @ Peak Pulse Current

Low Leakage < 5

碌A(chǔ)

above 10 V

Maximum Temperature Coefficient Specified

UL 497B for Isolated Loop Circuit Protection

Response Time is Typically < 1 ns

AXIAL LEAD

CASE 17

PLASTIC

Mechanical Characteristics:

CASE:

Void-free, Transfer-molded, Thermosetting plastic

FINISH:

All external surfaces are corrosion resistant and leads are

readily solderable

MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:

230擄C,

1/16鈥?from the case for 10 seconds

POLARITY:

Cathode band does not imply polarity

MOUNTING POSITION:

Any

MAXIMUM RATINGS

Rating

Peak Power Dissipation (Note 1.)

@ T

L

鈮?/div>

25擄C

Steady State Power Dissipation

@ T

L

鈮?/div>

75擄C, Lead Length = 3/8鈥?/div>

Derated above T

L

= 75擄C

Thermal Resistance,

Junction鈥搕o鈥揕ead

Operating and Storage

Temperature Range

Symbol

P

PK

P

D

Value

600

5

50

R

qJL

T

J

, T

stg

15

鈥?55 to +150

Unit

Watts

L

P6KE

xxxCA

YYWW

L = Assembly Location

P6KExxxCA = ON Device Code

YY = Year

WW = Work Week

ORDERING INFORMATION

Device

P6KExxxCA

Package

Axial Lead

Shipping

1000 Units/Box

4000/Tape & Reel

mW/擄C

擄C/W

擄C

P6KExxxCARL

1. Nonrepetitive current pulse per Figure 3 and derated above T

A

= 25擄C

per Figure 2.

*Please see P6KE6.8A 鈥?P6KE200A for Unidirectional devices.

漏

Semiconductor Components Industries, LLC, 2001

1

March, 2001 鈥?Rev. 1

Publication Order Number:

P6KE6.8CA/D
