PCB Relay

Subminiature Relay that Switches up to

5A

Subminiature: 20 (L) x 10 (W) x 10 (H) mm.

Low power consumption: 200 mW.

Unique moving loop armature reduces relay size,

magnetic interference, and contact bounce time.

Single- and double-winding latching types also

available.

G6B

Ordering Information

Contact form

SPST-NO

SPST-NO + SPST-NC

DPST-NO

DPST-NC

Note:

Terminal type

Straight PCB

Self-clinching PCB

Straight PCB

Self-clinching PCB

Straight PCB

Self-clinching PCB

Straight PCB

Self-clinching PCB

Single-side stable

G6B-1114P-US

G6B-1114C-US

G6B-2114P-US

G6B-2114C-US

G6B-2214P-US

G6B-2214C-US

G6B-2014P-US

G6B-2014C-US

Single winding

latching

G6BU-1114P-US

G6BU-1114C-US

---

---

---

---

---

---

Double-winding

latching

G6BK-1114P-US

G6BK-1114C-US

When ordering, add the rated coil voltage to the model number.

Example: G6B-1114P-US 12 VDC

Rated coil voltage

Model Number Legend:

G6B -

1

-

2

3 4 5

-

6

7

3. Contact Type

1:

Single button

7:

High-capacity

4. Enclosure Rating

4:

Plastic-sealed

5. Terminals

Straight PCB

P:

C:

Self-clinching PCB

6. Approved Standards

US: UL/CSA certified

7. Rated Coil Voltage

5, 6, 12, 24 VDC

VDC

1. Relay Function

None:Single-side stable

U:

Single-winding latching

K:

Double-winding latching

2. Contact Form

21: SPST-NO + SPST-NC

22: DPST-NO

20: DPST-NC

11: SPST-NO

1
