STP5NK80Z

STP5NK80ZFP

N-channel 800V - 1.9鈩?- 4.3A - TO-220/TO-220FP

Zener-protected SuperMESH鈩?Power MOSFET

General features

Type

STP5NK80Z

STP5NK80ZFP

鈻?/div>

DSS

(@Tjmax)

800 V

DS(on)

< 2.4

鈩?/div>

< 2.4

鈩?/div>

4.3 A

100% avalanche tested

Gate charge minimized

Very low intrinsic capacitances

Very good manufacturing repeatibility

TO-220

TO-220FP

Description

The SuperMESH鈩?series is obtained through an

extreme optimization of ST鈥檚 well established

strip-based PowerMESH鈩?layout. In addition to

pushing on-resistance significantly down, special

care is taken to ensure a very good dv/dt

capability for the most demanding applications.

Such series complements ST full range of high

voltage MOSFETs including revolutionary

MDmesh鈩?products.

Internal schematic diagram

Applications

鈻?/div>

Switching application

Order codes

Part number

STP5NK80Z

STP5NK80ZFP

Marking

P5NK80Z

P5NK80ZFP

Package

TO-220

TO-220FP

Packaging

Tube

August 2006

Rev 4

1/15

www.st.com
