Oscilloscopes
FEATURES AND BENEFITS
60 MHz or 100 MHz with 1 GS/s
Sample Rate on all Channels
Dual Timebase
Automatic Measurements
Multi-Language User Interface
Autoset
Waveform and Setup Memories
Extended Capabilities are Provided
with Optional Modules, Software
and Probing
APPLICATIONS
Design/Debug
Service and Repair
Tektronix鈥?Most Popular DSO
The TDS 200 Oscilloscopes
have quickly become the
benchmark for low-cost oscil-
loscopes. Offering an unbeat-
able combination of perfor-
mance, reliability and versa-
tility, the TDS 200 Series
offers breakthrough digital
and real-time advantages at
low-cost analog oscilloscope
prices. And with the intro-
duction of the TDS 224, Tek-
tronix now brings the digital
performance of the TDS 200
to customers that need four
full-featured channels.
Affordable Digital Performance
Versatility and Flexibility
The portable form factor pro-
vides increased versatility,
allowing the instrument to be
easily moved or safely stored
away when not in use.
Easy to Use
Manufacturing Test and Quality
Control
Education/Training
The user interface is similar
to that of an analog oscillo-
scope, but with improve-
ments that reduce learning
time and increase efficiency
The Personal Oscilloscope
No other digital oscilloscope
offers as much bandwidth
and sample rate for the price.
By sampling at 10 and 16
times their bandwidths on all
channels, the TDS 200 Series
oscilloscopes provide accu-
rate real-time acquisition up
to their full bandwidth.
The TDS 200 Series oscillo-
scopes are designed for peo-
ple who demand the ultimate
in oscilloscope value. If an
inexpensive yet high perfor-
mance oscilloscope is needed
for the bench, production
line, or training lab, a TDS
200 Series Digital Real-Time
Oscilloscope is the best
choice.
Copyright 漏 1999 Tektronix, Inc. All rights reserved.
