STP140NF75

STB140NF75 - STB140NF75-1

N-channel 75V - 0.0065鈩?- 120A - D

PAK/I

/TO-220

STripFET鈩?III Power MOSFET

General features

Type

STB140NF75

STB140NF75-1

STP140NF75

DSS

75V

DS(on)

<0.0075鈩?/div>

120A

(1)

120A

(1)

120A

(1)

TO-220

PAK

1. Current limited by package

鈻?/div>

100% avalanche tested

Description

This Power MOSFET is the latest development of

STMicroelectronis unique "Single Feature Size鈩?quot;

strip-based process. The resulting transistor

shows extremely high packing density for low on-

resistance, rugged avalanche characteristics and

less critical alignment steps therefore a

remarkable manufacturing reproducibility.

PAK

Internal schematic diagram

Applications

鈻?/div>

Switching application

Order codes

Part number

STB140NF75T4

STB140NF75-1

STP140NF75

Marking

B140NF75

P140NF75

Package

PAK

TO-220

Packaging

Tape & reel

Tube

June 2006

Rev 4

1/18

www.st.com
