Cylindrical High-Intensity Green LED

(5 mm)

OVLLG8C7

Wide viewing angle

High-brightness indicator

Industry standard lead spacing

Unique lens shape for flexible applications

Product Photo Here

The

OVLLG8C7

is designed for superior performance in signage and lighting applications that require wide-angle,

uniform light output. This device combines a high-intensity InGaN LED with a unique flat-topped T-1戮 package to

provide both high brightness and a wide spatial radiation pattern.

Applications

Channel letter and other signage backlighting

Decorative architectural indoor and outdoor lighting accents

Industrial and consumer indicators

Part Number

OVLLG8C7

Material

InGaN

Emitted Color

Green

Intensity Typ. mcd

670

Lens Color

Water Clear

1 ANODE

2 CATHODE

DIMENSIONS ARE IN INCHES AND [MILLIMETERS].

RoHS

Moisture

DO NOT LOOK DIRECTLY

AT LED WITH UNSHIELDED

EYES OR DAMAGE TO

RETINA MAY OCCUR.

OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.

OPTEK Technology Inc. 鈥?/div>

1645 Wallace Drive, Carrollton, Texas 75006

Phone: (972) 323-2200 or (800) 341-4747

FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com

Issue A

10/05

Page 1 of 4

產品培訓模塊
LED Thermal Management
標準包裝
500
類別
光電元件
家庭
LED -
系列
-
顏色
綠
Millicandela 等級
670mcd
正向電壓
3.4V
電流 - 測試
20mA
波長 - 主
525nm
波長 - 峰值
521nm
視角
85°
透鏡類型
透明
透鏡樣式/尺寸
圓形，帶平頂，5mm，T-1 3/4
封裝/外殼
徑向
尺寸/尺寸
-
高度
6.80mm
安裝類型
通孔
包裝
散裝
在特定電流下的光通量 - 測試
-
其它名稱
365-1202
