OSC-15801
SYNCHRO/RESOLVER/INDUCTOSYN
廬
REFERENCE OSCILLATOR
DESCRIPTION
The OSC-15801 is a quadrature
power oscillator with two outputs that
are 90擄 out of phase. These outputs
provide both the reference and quad-
rature signals, simultaneously, mak-
ing the OSC-15801 ideally suited for
Inductosyn applications.
The oscillator鈥檚 outputs are pin-pro-
grammable for both frequency and
amplitude. The output frequency can
be programmed from 400 Hz to 20
kHz by simply connecting two exter-
nal capacitors. The Reference output
voltage, 8.8 Vrms at 20 kHz, can be
scaled down by connecting a single
resistor.
FEATURES
鈥?/div>
Quadrature Reference Output
Voltages for Inductosyn
Applications
APPLICATIONS
Packaged in an 18-pin hermetic DDIP,
the OSC-15801 operates over a tem-
perature range of -55擄C to +125擄C.
This, combined with its small size and
programmable output voltage and fre-
quency capabilities, makes it an
excellent choice for use in Inductosyn
applications.
鈥?/div>
Programmable Output Frequency
from 400 Hz to 20 kHz
鈥?/div>
Small 18-Pin DDIP
鈥?/div>
Scalable Reference Output
鈥?/div>
-55擄C to +125擄C Operating
Temperature Range
REF OUT -90藲
Cext
C1
+15 VDC
Rext
PA IN
30k
30k
GND
-15 VDC
QUAD OSCILLATOR
REF
OUT
-
PA OUT
+
C2
GND
Cext
C2
FIGURE 1. OSC-15801 BLOCK DIAGRAM
漏
1981, 1999 Data Device Corporation
廬
Inductosyn is a registered trademark of Farrand Controls Corporation.
