TTL Compatible Output
16KV Isolation
2Mbd Transfer Rate
Creepage Path: 0.970鈥?(24.64mm)
Air Path: 0.970鈥?(24.64mm)
Low Propagation Delay Time
OPTEK Technology
Product Photo Here
The OPI1268 is a high voltage isolator with a digital output which is capable of high speed data transmission.
This device is capable of DC and AC voltage isolation between the input and output circuitry while providing
TTL signal integrity.
The input of the OPI1268 consists of a high efficiency GaAlAs LED which is optically coupled to the output opti-
cal IC. A photodiode in the output IC detects the incoming modulated light and converts it to a proportionate
current. This current is fed into a high gain, linear amplifier which is temperature, current and voltage compen-
sated. The result is a highly stable digital output in an open collector inverter configuration.
Applications include:
鈥?/div>
High Voltage Isolation
鈥?/div>
PCBoard Power System Isolation
鈥?/div>
Industrial Equipment Power Isolation
鈥?/div>
Medical Equipment Power Isolation
Ordering Information
Please order part number OPI1268
Optek reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc.鈥?/div>
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (800) 341-4747 FAX: (972) 323鈥?2396 sensors@optekinc.com www.optekinc.com
A subsidiary of
TT electronics plc
Issue A
07.04
OPI1268 產(chǎn)品屬性
Optek
高速光耦合器
詳細信息
1 Channel
2 MBps
1.6 V
3 V
50 mA
100 mW
+ 100 C
- 40 C
DC
16000 V
25 mA
50 mA
1.3 V
Logic Gate Photo IC
