0.430" (10.92 mm) deep slot
Description
The OPB815L consists of an infrared
emitting diode and an NPN silicon
phototransistor mounted in a low cost
plastic housing on opposite sides of a
0.375" (9.53 mm) wide, 0.430" (10.92
mm) deep slot. Phototransistor switching
takes place whenever an opaque object
passes through the slot. Available with
wire leads as OPB815W.
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Storage and Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . -40
o
C to +85
o
C
Lead Soldering Temperature [1/16 inch (1.6 mm) from case for 5 sec. with soldering
iron] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
o
C
(1)
Input Diode
Continuous Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 mA
Peak Forward Current (1
碌s
pulse width, 300 pps) . . . . . . . . . . . . . . . . . . . . . . . 3.0 A
Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.0 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mW
(2)
Output Phototransistor
Collector-Emitter Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 V
Emitter-Collector Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mW
(2)
Notes:
(1) RMA flux is recommended. Duration can be extended to 10 sec. max when flow soldering.
(2) Derate linearly 1.67 mW/
o
C above 25
o
C.
(3) Methanol or isopropanol are recommended as cleaning agents. Plastic housing is soluble in
chlorinated hydrocarbons and ketones.
(4) All parameters tested using pulse technique.
