0.190鈥?4.83 mm) gap
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Storage and Operating Temperature. . . . . . . . . . . . . . . . . . . . . . . . . -40擄C to +100擄C
Lead Soldering Temperature [1/16 inch (1.6 mm) from case for 5 sec. with soldering
iron] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260擄C
(4)
Input Diode
Forward DC Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 mA
Peak Forward Current (1
碌s
pulse width, 300 pps) . . . . . . . . . . . . . . . . . . . . . . . . 3.0 A
Reverse DC Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.0 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mW
(2)
Output Photodiode
Reverse Breakdown Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 V
Power Dissipation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 mW
NOTES:
(1) RMA flux is recommended. Duration can be ex tended to 10 seconds maximum when flow
soldering. Maximum 20 grams force may be applied to leads when soldering.
(2) Derate linearly 1.33 mW/擄C above 25擄C.
(3) Methanol and isopropanol are recommended as cleaning agents. Plastic housings are
soluble in chlorinated hydrocarbons and ketones.
Description
The OPB621 slotted optical switch
consists of an infrared emitting diode and
a PIN photodiode.
The low t
r
/t
f
of the PIN photodiode is
ideal for high speed operation. The
polysulfone housing is opaque to visible
light but transmissive to infrared. The
sensitivity to ambient radiation is
minimized.
