12, 1 watt LEDs per ring
Mono-color per strip (Blue, Green, Red, Yellow, White)
Two component beam angle options (120擄 or 40擄)
Universal connector (Tyco 2-292173-2 mates with 173977-2)
RoHS Compliant
OPA730_ (120擄 Beam Angle)
Product Photo Here
OPA730_D (40擄 Beam Angle)
The
OPA730
Series are designed for areas where lighting intensity and reliability
are essential. The light beam angles of 40擄 and 120擄 are ideal for illuminating small and medium size areas while
requiring minimal space. A patented substrate is used to ensure the best heat dissipation of any light assembly in
the industry.
For custom colors and design contact your OPTEK representative.
Electrical / Optical Characteristics: T
A
=25擄C, I
F
=700mA
Part Number
OPA730Y
OPA730B
OPA7309G
OPA730R
OPA730W
OPA730YD
OPA730BD
OPA730GD
OPA730RD
OPA730WD
Typical Forward Voltage (V)
15.0
21.6
21.6
15.0
21.6
15.0
21.6
21.6
15.0
21.6
Luminous Flux (lm)
420
108
576
312
576
420
108
576
312
576
40擄
120擄
Beam Angle
Color
Yellow
Blue
Green
Red
White
Yellow
Blue
Green
Red
White
+ Voltage
Dominant Wavelength
587 nm
470 nm
530 nm
625 nm
6,500擄K
587 nm
470 nm
530 nm
625 nm
6,500擄K
Ground
OPA730_
See OVSP_BCR4 for
component specifications
OPA730_D
See OVSP_4CR44 for
component specifications
DO NOT LOOK DIRECTLY AT LED WITH
UNSHIELDED EYES OR DAMAGE TO
RETINA MAY OCCUR.
RoHS
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. 鈥?/div>
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 visibleLED@optekinc.com www.optekinc.com
Issue A
04/06
Page 1 of 1
