OPA688U/2K5 Datasheet

  • OPA688U/2K5

  • Voltage-Feedback Operational Amplifier

  • 17頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

OPA688
O PA
688
www.ti.com
Unity Gain Stable, Wideband
VOLTAGE LIMITING AMPLIFIER
TM
FEATURES
q
q
q
q
q
q
q
HIGH LINEARITY NEAR LIMITING
FAST RECOVERY FROM OVERDRIVE: 2.4ns
LIMITING VOLTAGE ACCURACY:
鹵
15mV
鈥?dB BANDWIDTH (G = +1): 530MHz
SLEW RATE: 1000V/
碌
s
鹵
5V AND 5V SUPPLY OPERATION
HIGH GAIN VERSION: OPA689
APPLICATIONS
q
q
q
q
q
q
q
q
FAST LIMITING ADC INPUT BUFFERS
CCD PIXEL CLOCK STRIPPING
VIDEO SYNC STRIPPING
HF MIXERS
IF LIMITING AMPLIFIERS
AM SIGNAL GENERATION
NON-LINEAR ANALOG SIGNAL PROCESSING
COMPARATORS
DESCRIPTION
The OPA688 is a wideband, unity gain stable voltage-
feedback op amp that offers bipolar output voltage lim-
iting. Two buffered limiting voltages take control of the
output when it attempts to drive beyond these limits.
This new output limiting architecture holds the limiter
offset error to
鹵15mV.
The op amp operates linearly to
within 30mV of the output limit voltages.
The combination of narrow nonlinear range and low
limiting offset allows the limiting voltages to be set
within 100mV of the desired linear output range. A fast
2.4ns recovery from limiting ensures that overdrive sig-
nals will be transparent to the signal channel. Imple-
LIMITED OUTPUT RESPONSE
2.5
2.0
Input and Output Voltage (V)
menting the limiting function at the output, as opposed to
the input, gives the specified limiting accuracy for any
gain, and allows the OPA688 to be used in all standard
op amp applications.
Non-linear analog signal processing will benefit from
the OPA688鈥檚 sharp transition from linear operation to
output limiting. The quick recovery time supports high-
speed applications.
The OPA688 is available in an industry standard pinout
SO-8 package. For higher gain, or transimpedance appli-
cations requiring output limiting with fast recovery,
consider the OPA689.
DETAIL OF LIMITED OUTPUT VOLTAGE
2.10
2.05
2.00
V
H
= 鈥揤
L
= 2.0V
G = +2
1.5
Output Voltage (V)
1.0
0.5
0
鈥?.5
鈥?.0
鈥?.5
鈥?.0
鈥?.5
V
IN
V
O
1.95
1.90
1.85
1.80
1.75
1.70
1.65
1.60
Time (50ns/div)
V
O
Time (200ns/div)
Copyright 漏 1997, Texas Instruments Incorporated
SBOS082A
Printed in U.S.A. February, 2001
