OPA627AM Datasheet

  • OPA627AM

  • Precision High-Speed Difet OPERATIONAL AMPLIFIERS

  • 258.40KB

  • 13頁

  • BB

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
OPA
627
OPA627
OPA637
OPA
627
Precision High-Speed
Difet
廬
OPERATIONAL AMPLIFIERS
FEATURES
q
VERY LOW NOISE: 4.5nV/
鈭?/div>
Hz at 10kHz
q
FAST SETTLING TIME:
OPA627鈥?50ns to 0.01%
OPA637鈥?50ns to 0.01%
q
LOW V
OS
: 100
碌
V max
q
LOW DRIFT: 0.8
碌
V/
擄
C max
q
LOW I
B
: 5pA max
q
OPA627: Unity-Gain Stable
q
OPA637: Stable in Gain
鈮?/div>
5
APPLICATIONS
q
PRECISION INSTRUMENTATION
q
FAST DATA ACQUISITION
q
DAC OUTPUT AMPLIFIER
q
OPTOELECTRONICS
q
SONAR, ULTRASOUND
q
HIGH-IMPEDANCE SENSOR AMPS
q
HIGH-PERFORMANCE AUDIO CIRCUITRY
q
ACTIVE FILTERS
High frequency complementary transistors allow in-
creased circuit bandwidth, attaining dynamic perform-
ance not possible with previous precision FET op
amps. The OPA627 is unity-gain stable. The OPA637
is stable in gains equal to or greater than five.
DESCRIPTION
The OPA627 and OPA637
Difet
operational amplifi-
ers provide a new level of performance in a precision
FET op amp. When compared to the popular OPA111
op amp, the OPA627/637 has lower noise, lower offset
voltage, and much higher speed. It is useful in a broad
range of precision and high speed analog circuitry.
The OPA627/637 is fabricated on a high-speed, dielec-
trically-isolated complementary NPN/PNP process. It
operates over a wide range of power supply voltage鈥?/div>
鹵4.5V
to
鹵18V.
Laser-trimmed
Difet
input circuitry
provides high accuracy and low-noise performance
comparable with the best bipolar-input op amps.
Trim
1
Difet
fabrication achieves extremely low input bias
currents without compromising input voltage noise
performance. Low input bias current is maintained
over a wide input common-mode voltage range with
unique cascode circuitry.
The OPA627/637 is available in plastic DIP, SOIC
and metal TO-99 packages. Industrial and military
temperature range models are available.
7
+V
S
5
Trim
Output
6
+In
3
鈥揑n
2
Difet
廬
, Burr-Brown Corp.
鈥揤
S
4
International Airport Industrial Park 鈥?Mailing Address: PO Box 11400, Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 鈥?Tel: (520) 746-1111 鈥?Twx: 910-952-1111
Internet: http://www.burr-brown.com/ 鈥?FAXLine: (800) 548-6133 (US/Canada Only) 鈥?Cable: BBRCORP 鈥?Telex: 066-6491 鈥?FAX: (520) 889-1510 鈥?Immediate Product Info: (800) 548-6132
漏1989 Burr-Brown Corporation
PDS-998H
Printed in U.S.A. March, 1998

OPA627AM 產品屬性

  • 20

  • 集成電路 (IC)

  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • Difet®

  • 通用

  • 1

  • -

  • 55 V/µs

  • 16MHz

  • -

  • 2pA

  • 130µV

  • 7mA

  • 45mA

  • 9 V ~ 36 V，±4.5 V ~ 18 V

  • -25°C ~ 85°C

  • 通孔

  • TO-99-8 金屬罐

  • TO-99-8

  • 管件
