OPA2686U Datasheet

  • OPA2686U

  • Voltage-Feedback Operational Amplifier

  • 19頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
OPA
268
6
OPA2686
Dual, Wideband, Low Noise,
Voltage Feedback OPERATIONAL AMPLIFIER
TM
FEATURES
q
HIGH GAIN BANDWIDTH: 1.6GHz
q
LOW INPUT VOLTAGE NOISE: 1.4nV/鈭欻z
q
VERY LOW DISTORTION: 鈥?0dBc (5MHz)
q
LOW SUPPLY CURRENT: 12mA/chan.
q
HIGH CHANNEL ISOLATION: 70dB
q
鹵
5V OPERATION
q
STABLE FOR GAINS
鈮?/div>
+7
APPLICATIONS
q
LOW NOISE, DIFFERENTIAL AMPLIFIERS
q
xDSL RECEIVER AMPLIFIER
q
ULTRASOUND HIGH GAIN PREAMP
q
DIFFERENTIAL ADC PREAMP
q
MATCHED I AND Q CHANNEL AMPLIFIERS
q
MATCHED TRANSIMPEDANCE AMPLIFIERS
q
PROFESSIONAL AUDIO DUAL
TRANSIMPEDANCE
DESCRIPTION
The OPA2686 provides two very low noise, high gain
bandwidth, voltage feedback op amps in a single
package. Operating from a low 12mA/channel quies-
cent current, each channel provides a 1.4nV/鈭欻z input
voltage noise with a 1.6GHz gain bandwidth product.
Minimum stable gain is specified at +7V/V while
exceptional flatness is guaranteed at a gain of +10.
The combination of low noise, high slew rate
(600V/碌s), and broad bandwidth allow exceptional xDSL
differential receivers to be implemented. Additionally,
de-compensated, low-noise voltage-feedback op amps
are ideal for broadband transimpedance requirements.
The dual channel OPA2686 provides matched channels
for high speed differencing transimpedance require-
ments. With over 200MHz bandwidth at a gain of
20dB, excellent gain and phase matching is provided at
IF frequencies for matched I and Q channel amplifiers.
OPA2686 RELATED PRODUCTS
SINGLES
OPA643
OPA686
OPA687
INPUT NOISE
VOLTAGE (nV/
鈭?/div>
Hz)
2.3
1.3
0.95
GAIN BANDWIDTH
PRODUCT (MHz)
800
1600
3600
1/2
OPA2686
R
G
R
G
R
F
R
F
Passive
Filter
Analog
Front
End
Diplexer
1/2
OPA2686
Driver
Low Noise VDSL Receiver
International Airport Industrial Park 鈥?Mailing Address: PO Box 11400, Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 鈥?Tel: (520) 746-1111
Twx: 910-952-1111 鈥?Internet: http://www.burr-brown.com/ 鈥?Cable: BBRCORP 鈥?Telex: 066-6491 鈥?FAX: (520) 889-1510 鈥?Immediate Product Info: (800) 548-6132
廬
漏
1998 Burr-Brown Corporation
1
PDS-1371B
OPA2686
May, 2000
Printed in U.S.A.
SBOS064

OPA2686U 產品屬性

  • 100

  • 集成電路 (IC)

  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • SpeedPlus™

  • 電壓反饋

  • 2

  • -

  • 600 V/µs

  • 1.6GHz

  • -

  • 10µA

  • 350µV

  • 24.8mA

  • 80mA

  • ±4.5 V ~ 6 V

  • -40°C ~ 85°C

  • 表面貼裝

  • 8-SOIC（0.154"，3.90mm 寬）

  • 8-SOIC

  • 管件
