OPA2652
For most current data sheet and other product
information, visit www.burr-brown.com
Dual, 700MHz, Voltage-Feedback
OPERATIONAL AMPLIFIER
TM
FEATURES
q
WIDEBAND BUFFER: 700MHz, G = +1
q
WIDEBAND LINE DRIVER: 200MHz, G = +2
q
HIGH OUTPUT CURRENT: 140mA
q
LOW SUPPLY CURRENT: 5.5mA/Ch
q
ULTRA-SMALL PACKAGE: SOT23-8
q
LOW dG/d蠁 : 0.05%/0.03
擄
q
HIGH SLEW RATE: 335V/
碌
sec
q
SUPPLY VOLTAGE:
鹵
3V to
鹵
6V
DESCRIPTION
The OPA2652 is a dual, low-cost, wideband voltage-
feedback amplifier intended for price sensitive applica-
tions. It features a high gain bandwidth product of 200MHz
on only 5.5mA/chan quiescent current. Intended for op-
eration on
鹵5V
supplies, it will also support applications
on a single supply from +6V to +12V with 140mA output
current. Its classical differential input, voltage-feedback
design allows wide application in active filters, integra-
tors, transimpedance amplifiers, and differential receiv-
ers.
The OPA2652 is internally compensated for unity gain
stability. It has exceptional bandwidth (700MHz) as a unity
gain buffer, with little peaking (0dB typically). Excellent
DC accuracy is achieved with a low 1.5mV input offset
voltage and 300nA input offset current.
RELATED PRODUCTS
SINGLES
OPA650
OPA680
OPA631
OPA634
DUALS
OPA2650
OPA2680
OPA2631
OPA2634
TRIPLES
鈥?/div>
OPA3680
鈥?/div>
鈥?/div>
QUADS
OPA4650
鈥?/div>
鈥?/div>
鈥?/div>
NOTES
鹵5V
Spec
+5V Capable
+3V Capable
+3V Capable
APPLICATIONS
q
A/D DRIVERS
q
CONSUMER VIDEO
q
ACTIVE FILTERS
q
PULSE DELAY CIRCUITS
q
LOW COST UPGRADE TO THE AD8056
OR EL2210
200鈩?/div>
鈥?/div>
402鈩?/div>
+5V
1/2
OPA2652
24.9鈩?0.1碌F
22pF
1.00k鈩?/div>
0.1碌F
CM
+In
+5V
VIN
133鈩?/div>
鈥揑n
1.00k鈩?/div>
ADS807
12-Bit
53MHz
200鈩?/div>
+
402鈩?/div>
24.9鈩?0.1碌F
22pF
1/2
OPA2652
133鈩?/div>
鈥?V
Differential ADC Driver
International Airport Industrial Park 鈥?Mailing Address: PO Box 11400, Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 鈥?Tel: (520) 746-1111
Twx: 910-952-1111 鈥?Internet: http://www.burr-brown.com/ 鈥?Cable: BBRCORP 鈥?Telex: 066-6491 鈥?FAX: (520) 889-1510 鈥?Immediate Product Info: (800) 548-6132
漏 2000 Burr-Brown Corporation
PDS-1588B
Printed in U.S.A. June, 2000
SBOS125
