OPA2631 Datasheet

  • OPA2631

  • OPA2631 - Dual. Low Power. Single-Supply OPERATIONAL AMPLIFI...

  • 146.13KB

  • 17頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
OPA
263
1
OPA2631
For most current data sheet and other product
information, visit www.burr-brown.com
Dual, Low Power, Single-Supply
OPERATIONAL AMPLIFIER
TM
FEATURES
q
HIGH BANDWIDTH: 75MHz (G = +2)
q
LOW SUPPLY CURRENT: 6mA/ch
q
+3V AND +5V OPERATION
q
INPUT RANGE INCLUDES GROUND
q
4.8V OUTPUT SWING ON +5V SUPPLY
q
HIGH SLEW RATE: 100V/
碌
s
q
LOW INPUT VOLTAGE NOISE: 6nV/鈭欻z
DESCRIPTION
The OPA2631 is a dual, low power, voltage-feedback
amplifier designed to operate on a single +3V or +5V
supply. Operation on
鹵5V
or +10V supplies is also
supported. The input range extends below ground and
to within 1V of the positive supply. Using complemen-
tary common-emitter outputs provides an output swing
to within 30mV of ground and 130mV of the positive
supply. The high output drive current and low differen-
tial gain and phase errors also make it ideal for single-
supply consumer video products.
Low distortion operation is ensured by the high gain
bandwidth (68MHz) and slew rate (100V/碌s), making
the OPA2631 an ideal input buffer stage to 3V and 5V
CMOS converters. Unlike other low power, single-
supply amplifiers, distortion performance improves as
the signal swing is decreased. A low 6nV/鈭欻z input
voltage noise supports wide dynamic range operation.
The OPA2631 is available in an industry standard
SO-8 package. Where a single channel, single-supply
operational amplifier is required, consider the OPA631
and OPA632. Where higher full-power bandwidth and
lower distortion are required, consider the OPA2634.
RELATED PRODUCTS
+3V
Medium Speed, No Disable
With Disable
SINGLES
OPA631
OPA632
OPA634
OPA635
DUALS
OPA2631
鈥?/div>
OPA2634
鈥?/div>
APPLICATIONS
q
q
q
q
q
q
DIFFERENTIAL RECEIVERS/DRIVERS
ACTIVE FILTERS
MATCHED I AND Q CHANNEL AMPLIFIERS
CCD IMAGING CHANNELS
LOW POWER ULTRASOUND
PORTABLE CONSUMER ELECTRONICS
SPICE model available at www.burr-brown.com
+3V
2.26k鈩?/div>
374鈩?/div>
V
IN
1/2
OPA2631
100鈩?/div>
ADS901
10-Bit
20Msps
22pF
High Speed, No Disable
With Disable
562鈩?/div>
750鈩?/div>
International
Airport Industrial Park 鈥?Mailing Address: PO Box 11400, Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 鈥?Tel: (520) 746-1111
Twx: 910-952-1111 鈥?Internet: http://www.burr-brown.com/ 鈥?Cable: BBRCORP 鈥?Telex: 066-6491 鈥?FAX: (520) 889-1510 鈥?Immediate Product Info: (800) 548-6132
漏 1999 Burr-Brown Corporation
PDS-1378A
Printed in U.S.A. August, 1999
