New circuit techniques and special laser trimming of
dynamic circuit performance yield very low harmonic
distortion. The result is an op amp with exceptional
sound quality. The low-noise FET input of the
OPA2604 provides wide dynamic range, even with high
source impedance. Offset voltage is laser-trimmed to
minimize the need for interstage coupling capacitors.
The OPA2604 is available in 8-pin plastic mini-DIP
and SO-8 surface-mount packages, specified for the
鈥?5擄C to +85擄C temperature range.
* Patents Granted:
#5053718, 5019789
(8)
V+
(+)
(3, 5)
(鈥?
(2, 6)
Distortion
Rejection
Circuitry*
Output
Stage*
(1, 7)
V
O
(4)
V鈥?/div>
