OPA2541
Dual High Power
OPERATIONAL AMPLIFIER
FEATURES
q
OUTPUT CURRENTS TO 5A
q
POWER SUPPLIES TO
鹵
40V
q
FET INPUT
q
ELECTRICALLY ISOLATED CASE
DESCRIPTION
The OPA2541 is a dual power operational amplifier
capable of operation from power supplies up to
鹵40V
and output currents of 5A continuous. With two mono-
lithic power amplifiers in a single package it provides
unequaled functional density.
The industry-standard 8-pin TO-3 package is isolated
from all internal circuitry allowing it to be mounted
directly to a heat sink without insulators which de-
grade thermal performance. Internal circuitry limits
output current to approximately 6A.
The OPA2541 is available in both industrial and
military temperature range versions.
APPLICATIONS
q
q
q
q
q
MOTOR DRIVER
SERVO AMPLIFIER
SYNCRO/RESOLVER EXCITATION
VOICE COIL DRIVER
BRIDGE AMPLIFIER
q
PROGRAMMABLE POWER SUPPLY
q
AUDIO AMPLIFIER
+V
S
(2)
鈥揑n
(4, 8)
+In
(3, 7)
Out
(5, 1)
鈥揤
S
(6)
International Airport Industrial Park 鈥?Mailing Address: PO Box 11400
Tel: (520) 746-1111 鈥?Twx: 910-952-1111 鈥?Cable: BBRCORP 鈥?/div>
漏
鈥?Tucson, AZ 85734 鈥?Street Address: 6730 S. Tucson Blvd. 鈥?Tucson, AZ 85706
Telex: 066-6491 鈥?FAX: (520) 889-1510 鈥?Immediate Product Info: (800) 548-6132
PDS-768B
Printed in U.S.A. October, 1993
1987 Burr-Brown Corporation
