ON1024 Datasheet

  • ON1024

  • Photo lnterrupter

  • 4頁

  • PANASONIC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Transmissive Photosensors (Photo lnterrupters)
CNZ1021
(ON1021)
, CNZ1023
(ON1023)
,
CNA1009H
(ON1024)
Photo lnterrupter
For contactless SW, object detection
鈻?/div>
Overview
CNZ1021, CNZ1023 and CNA1009H are a transmis-
sive photosensor in which a high efficiency GaAs infra-
red light emitting diode is used as the light emitting ele-
ment, and a high sensitivity phototransistor is used as
the light detecting element. The two elements are ar-
ranged so as to face each other, and objects passing be-
tween them are detected.
鈻?/div>
Features
鈥?/div>
Highly precise position detection: 0.25 mm
鈥?/div>
Gap width: 3 mm (CNZ1021, CNZ1023)
5 mm (CNA1009H)
鈥?/div>
The type directly attached to PCB ....... CNZ1021
Screw-fastened type (one side) ............ CNZ1023
The type directly attached to PCB ....... CNA1009H
(with a positioning pins)
CNZ1023
Unit: mm
CNZ1021
Unit: mm
危
危
18.0
12.0
(2.5)
5.0
(2.5)
2.0
12.0
12.0
鹵0.15
5.0
0.4
鹵0.1
(4-R2)
Device
center
2.1
鹵0.15
(C1.2)
2-R1.5
6.0
3.5
(2-0.45)
(2.54)
SEC. A-A'
3.0鹵0.15
A
0.4鹵0.1
Device
center
2.1鹵0.15
(C1.2)
3.0
鹵0.15
A
10.0
10.0
10.0 min.
10.0 min.
2.5
A'
蠁3.0
-0
(2-0.45)
(7.6)
2.5
+0.15
A'
(2-0.45)
(7.6)
(2-0.45)
(2.54)
SEC. A-A'
2
3
1
4
1: Anode
2: Cathode
3: Collector
4: Emitter
PISTR104-001 Package
Unit: mm
2
3
1
4
1: Anode
2: Cathode
3: Collector
4: Emitter
PISTR104-003 Package
CNA1009H
危
14.0
5.0
鹵0.15
6.0
5.0
0.5
鹵0.1
Device
center
(C1)
(2.5)
A
10.0
10.0 min.
2-0.7
2.5
A'
2-蠁0.7
鹵0.1
(2-0.45)
(2-0.45)
(2.54)
SEC. A-A'
2
3
(10.0)
5.2
鹵0.1
1
2.35
鹵0.1
4
6.6
鹵0.1
1: Anode
2: Cathode
3: Collector
4: Emitter
PISTR104-004 Package
(Note) 1. Tolerance unless otherwise specified is
鹵0.3
2. ( ) Dimension is reference
2.2鹵0.15
Note) The part numbers in the parenthesis show conventional part number.
Publication date: April 2004
SHG00017BED
3.0
-0
0.5
+0.15
1
