PD-94474A

1 M Rad(Si) Low Dropout

Linear Regulator

Hermetic Package

OMR9600SC

OMR9600SF

+ 3.3Vin to +1.8Vout at 3.0A

Product Summary

Part Number

OMR9600SC

OMR9600SF

3.0A

Vin

3.3V

Vout

1.8V

Package

MO-078AA

8-pin Flatpack

MO-078AA

Features:

The OMR9600 is a radiation hardened, low dropout linear

regulator designed specifically for space applications. This

product has been characterized to a total ionizing dose of

1 M Rad (Si) per MIL-STD-883, Method 1019, Condition A

at both high and low dose rates under biased and unbi-

ased conditions to account for ELDRS effects in bipolar

devices. The low dropout voltage of 1.1V @ 3A makes the

part particularly useful for applications requiring low noise

and higher efficiency.

Total dose and low dose capabilitiy to 1M

Rad(Si) allows use in space applications

Low dropout of 1.1 volts significantly re

duces power consumption

Low noise, higher efficiency

Remote shutdown permits power

sequencing to be easily implemented

Hermetic MO-078AA (TO-258AA) and 8-

lead flat pack ensure higher reliability

K-level screened

Absolute Maximum Ratings

Symbol

V in

TOT

RTHJC

THJC

TSTG

Parameter

Output Current

Input Voltage

Power Dissipation TC=25

Thermal Resistance, Junction to Case (MO-078AA)

Thermal Resistance, Junction to Case (8 lead flatpack)

Operating Junction

Storage Temperature Range

Lead Temperature

Value

3.5

+7.0

6.5

-55 to +125

-65 to +150

300

Units

擄C/W

www.irf.com

6/05/02
