PD-94468A
Ultra Low Dropout
Linear Regulator
Hermetic Package
Product Summary
Part Number
OM8503SC
OM8503SF
Dropout
0.4 V
0.4 V
I
O
3.0A
3.0A
Vin
7.4V
7.4V
Vout
6.8V
6.8V
OM8503SC
OM8503SF
+7.4Vin to +6.8Vout at 3.0A
Package
MO-078AA
8-lead Flatpack
MO-078AA
Features:
The OM8503 is an ultra low dropout linear regulator de-
signed specifically for hi-rel applications. Housed in
either a 5 pin through hole or 8 lead surface mount pack-
age these regulators provide high reliability in military/
defense applications. The ultra low dropout voltage of 0.4V
@ 3A makes the part particularly useful for applications
requiring low noise and higher efficiency.
n
Ultra low dropout voltage of 0.4 volt sig-
n
n
n
n
nificantly reduces power consumption
Low noise, higher efficiency
Remote shutdown permits power
sequencing to be easily implemented
Hermetic MO-078AA (TO-258AA) and 8-
lead flat pack ensure higher reliability
Available H-level screened
Absolute Maximum Ratings
Symbol
Io
V in
P
TOT
RTHJC
R
THJC
TJ
TSTG
T
L
Parameter
Output Current
Input Voltage
Power Dissipation TC=25
o
C
Thermal Resistance, Junction to Case (MO-078AA)
Thermal Resistance, Junction to Case (8 lead flatpack)
Operating Junction
Storage Temperature Range
Lead Temperature
Value
3.5
+8.0
19
6.5
6.5
-55 to +125
-65 to +150
300
Units
A
V
W
擄C/W
擄C/W
o
C
o
C
o
C
