PD-94467A

Ultra Low Dropout

Linear Regulator

Hermetic Package

Product Summary

Part Number

OM8502SC

OM8502SF

Dropout

0.4 V

3.0A

Vin

5.6V

Vout

5.0V

OM8502SC

OM8502SF

+5.6Vin to +5.0Vout at 3.0A

Package

MO-078AA

8-lead Flatpack

MO-078AA

Features:

The OM8502 is an ultra low dropout linear regulator de-

signed specifically for hi-rel applications. Housed in

either a 5 pin through hole or 8 lead surface mount pack-

age, these regulators provide high reliability in military/

defense applications. The ultra low dropout voltage of 0.4V

@ 3A makes the part particularly useful for applications

requiring low noise and higher efficiency.

Ultra low dropout voltage of 0.4 volt

significantly reduces power consumption

Low noise, higher efficiency

Remote shutdown permits power

sequencing to be easily implemented

Hermetic MO-078AA (TO-258AA) and 8-

lead flat pack ensure higher reliability

Available H-level screened

Absolute Maximum Ratings

Symbol

V in

TOT

RTHJC

THJC

TSTG

Parameter

Output Current

Input Voltage

Power Dissipation TC=25

Thermal Resistance, Junction to Case (MO-078AA)

Thermal Resistance, Junction to Case (8 lead flatpack)

Operating Junction

Storage Temperature Range

Lead Temperature

Value

3.5

+7.0

6.5

-55 to +125

-65 to +150

300

Units

擄C/W

www.irf.com

8/20/02
