Isolated Hermetic Surface Mount Package
Adjustable Output Voltage
Eliminates Stocking Fixed Voltages
Built-In Thermal Overload Protection
Short Circuit Current Limiting
Product Is Available Hi-Rel Screened
Electrically Similar To Industry Standard Type LM137HV
DESCRIPTION
This three terminal negative regulator is supplied in a hermetically sealed metal
surface mount package. All protective features are designed into the circuit, including
thermal shutdown, current limiting and safe-area control. With heat sinking, they can
deliver over 1.0 amp of output current. This unit features output voltages that can be
trimmed using external resistors, from -1.2 volts to -47 volts.
ABSOLUTE MAXIMUM RATINGS
@ 25擄C
Input To Output Voltage Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 V
Operating Junction Temperature Range . . . . . . . . . . . . . . . . . . . . . . . - 55擄C to + 150擄C
Storage Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . - 55擄C to + 150擄C
Typical Power/Thermal Characteristics:
Rated Power:
T
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17.5W
T
A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3W
Thermal Resistance:
胃
JC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.0擄C/W
胃
JA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42擄C/W
Max. Lead Solder Temperature for 5 sec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225擄C
