Surface Mount Hermetic Package
Adjustable Output Voltage
Built-In Thermal Overload Protection
Short Circuit Current Limiting
Product Is Available Hi-Rel Screened
Electrically Similar To Industry Standard Type LM117
DESCRIPTION
This three terminal negative regulator is supplied in a hermetically sealed surface
mount package. All protective features are designed into the circuit, including
thermal shutdown, current limiting and safe-area control. With heat sinking, they can
deliver over 1.0 amp of output current. This unit features output voltages that can be
trimmed using external resistors, from 1.2 volts to 37 volts.
ABSOLUTE MAXIMUM RATINGS
Input to Output Voltage Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 V
Operating Junction Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . - 55擄C to + 150擄C
Storage Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . - 55擄C to + 150擄C
Typical Power/Thermal Characteristics:
Rated Power @ 25擄C
T
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17.5W
T
A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3W
Thermal Resistance:
胃
JC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5擄C/W
胃
JA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42擄C/W
Lead Temperature at Case (5 sec)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225擄C
PIN CONNECTION
1
2
MECHANICAL OUTLINE
.140
.500
.015
.075
.157
.140
.140
.075
.030
MIN.
3.5
Pin 1: Adjust
Pin 2: V
IN
3
.625
Pin 3: V
OUT
.415
.062
.375
TOP VIEW
SIDE VIEW
BOTTOM VIEW
4 11 R1
Supersedes 1 05 R0
3.5 - 113
1
2
