Dual Uncommitted MOSFETs
Isolated Hermetic Metal Package
Size 6 Die, High Energy, High Voltage
Fast Switching, Low Drive Current
Ease of Paralleling For Added Power
Low R
DS(on)
Available Screened to MIL-S-19500, TX, TXV And S Levels
DESCRIPTION
This series of hermetically packaged products feature the latest advanced MOSFET
and packaging technology. They are ideally suited for Military requirements where
small size, high performance and high reliability are required, and in applications
such as switching power supplies, motor controls, inverters, choppers, audio
amplifiers and high energy pulse circuits. This series also features avalanche high
energy capability at elevated temperatures.
MAXIMUM RATINGS
PART NUMBER
OM6227SS
OM6228SS
OM6230SS
OM6231SS
OM6232SS
OM6233SS
* See Mechanical Drawing
V
DS
400
500
1000
400
500
1000
R
DS(on)
.20
.27
1.30
.20
.27
1.30
I
D
(Amp)
24
22
10
24
22
10
*Package
S-6D
S-6D
S-6D
S-6E
S-6E
S-6E
3.1
SCHEMATIC
DRAIN
1
DRAIN
6
GATE
3
BODY
DIODE
GATE
4
BODY
DIODE
SOURCE
2
SOURCE
5
