E2V0021-37-X1

隆 electronic components

OL6204N-50/AP, OL6204N-50/BP

LASER DIODES

1.6

mm

High-Power DIP Module with 9mm Profile

OL6204N-50/AP, OL6204N-50/BP

GENERAL DESCRIPTION

The OL6204N-50 series are 1.6

mm

high-power modules in compact DIL packages with single

mode fiber pigtails. Having high power in pulsed operation, these devices can be used as light

sources for optical measurement equipment like OTDR systems.

FEATURES

鈥?Optical output power: 50 mW (pulse width 10

ms,

duty ratio 1 %)

鈥?Comact package: 14-pin DIP with 9mm high

鈥?Wavelength windows

OL6204N-50/AP for 1.625

mm

OL6204N-50/BP for 1.650

mm

APPLICATIONS

鈥?Optical measuring instruments

鈥?OTDRs

PACKAGE DIMENSIONS (Unit: mm)

鈥?OL6204N-50/AP, OL6204N-50/BP

5

f0.9

1

25.4

12.7

1.0

20.8

24

5.9

7.1

9

3.8

2.54

f0.45

TERMINAL CONNECTION

(BOTTOM VIEW)

#8

#14

(鈥?

LD

THERMISTOR

CASE

COOLER

6.35

FIBER

(+)

#7

#1

PIN No.

1

2

3

4

5

6

7

FUNCTION

COOLER ANODE

NC

NC

NC

LD ANODE and

CASE GROUND

NC

NC

PIN No.

FUNCTION

NC

8

LD CATHODE

9

LD ANODE and

10

CASE GROUND

THERMISTOR

11

THERMISTOR

12

NC

13

COOLER CATHODE

14

7.62

19

1/3
