E2V0012-37-X1
隆 electronic components
OL3204N-100/P
LASER DIODES
1.3
mm
High-Power DIP Module with 9mm Profile
OL3204N-100/P
GENERAL DESCRIPTION
The OL3204N-100P is a 1.3
mm
high-power laser in a 14-pin DIL package with 9mm profile.
Having extreme high output power in pulsed operation, this device can be used in optical
measurement equipment like OTDR systems.
FEATURES
鈥?Fiber output power: Pf=100 mW (pulse width 10
ms,
duty ratio 1 %)
鈥?Cooled DIL Package, 9mm hight
APPLICATIONS
鈥?Optical measurement equipment
鈥?OTDR
PACKAGE DIMENSIONS (Unit: mm)
鈥?OL3204N-100/P
5
f0.9
1
25.4
12.7
1.0
20.8
24
5.9
7.1
9
3.8
2.54
f0.45
TERMINAL CONNECTION
(BOTTOM VIEW)
#8
#14
(鈥?
LD
THERMISTOR
CASE
COOLER
6.35
FIBER
(+)
#7
#1
PIN No.
1
2
3
4
5
6
7
FUNCTION
COOLER ANODE
NC
NC
NC
LD ANODE and
CASE GROUND
NC
NC
PIN No.
FUNCTION
NC
8
LD CATHODE
9
LD ANODE and
10
CASE GROUND
THERMISTOR
11
THERMISTOR
12
NC
13
COOLER CATHODE
14
7.62
19
1/3
1
2
3
