OL3200N-5 Datasheet

  • OL3200N-5

  • 1.3 レm High-Power Laser-Diode DIP Module

  • 3頁

  • OKI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

E2V0014-37-X1
隆 electronic components
OL3200N-5
LASER DIODES
1.3
mm
High-Power Laser-Diode DIP Module
OL3200N-5
GENERAL DESCRIPTION
The OL3200N-5 is a 1.3
mm,
high-power laser diode DIP module with a single-mode fiber pigtail.
The high-performance OKI laser diode achieved a single-mode fiber output of over 5 mW.
This module is an optimal light source for long-haul fiber transmission systems and optical
measuring instruments.
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High output power: Pf=5 mW
Single-mode fiber
Hermetically-sealed,14-pin Dual-In-line Package (DIP)
Includes thermoelectric cooler and monitor photodiode for temperature and power control
APPLICATIONS
鈥?Line transmission systems
鈥?Subscriber loops
鈥?Optical measuring instruments
PACKAGE DIMENSIONS (Unit: mm)
鈥?OL3200N-5
5
f0.9
1
25.4
12.7
1.0
20.8
24
5.9
7.1
9
3.8
2.54
f0.45
TERMINAL CONNECTION
(BOTTOM VIEW)
#8
#14
(鈥?
THERMISTOR
CASE
COOLER
6.35
FIBER
PD LD
(+)
#7
#1
PIN No.
1
2
3
4
5
6
7
FUNCTION
COOLER ANODE
NC
NC
NC
LD ANODE,
CASE GROUND
and THERMISTOR
NC
PD CATHODE
PIN No.
FUNCTION
PD ANODE
8
LD CATHODE
9
LD ANODE,
10
CASE GROUND
and THERMISTOR
THERMISTOR
11
NC
12
NC
13
COOLER CATHODE
14
7.62
19
1/3
