Rev. 2.3 May 22, 2002
OD-B6212-ONUB
622Mbps(downstream)/622Mbps(upstream)
PON Optical Transceiver Module for ONU
FEATURES
n
Applicable to ITU-T G.983.1 ClassB
n
Applied to
ONU(Optical Network Unit)
for Single Fiber Bi-directional PON System.
n
Compact integrated Transceiver consists of
-1.3碌m Burst-mode Transmitter with Feed forward APC Circuit by use of ROM.
-1.5碌m Continuous-mode Receiver with Clock & Data recovery function.
-1.3/1.5碌m WDM function by
Planar Lightwave Circuit (PLC).
n
Optical output alarm (Tx ALM)
n
Optical output shutdown (Shutdown)
n
Optical input loss detection (Rx ALM)
OPERATING CONDITIONS
Parameter
Ambient Temperature
Power Supply Voltage
Power Supply Current
Unit
C
V
mA
o
Min.
鈥?40
+ 3.14
鈥?/div>
Values
Typ.
鈥?/div>
+ 3.30
300
Max.
+ 85
+ 3.46
500
1
2
