NXA66-12P3V3C Datasheet

  • NXA66-12P3V3C

  • Analog IC

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NXA66 Series | 66W DC/DC
66 Watt non-isolated DC/DC converters
NXA66 SERIES
Single output, selectable
Transient response from 0A to rated full load (up to 30A/碌s), recovery within 100碌sec
Democratic current sharing, no need for master/slave configuration
Programmable output voltage
Remote enable pin
Power good signal
True double ended differential remote sense
True output overvoltage protection with on-board fuse
Overcurrent foldback, short circuit protection
Overtemperature protection
Edge tab mount via gold plated fingers for low interconnect voltage drop
Small size 1.375 x 2.75 x 0.588 inches
High power density, small footprint
The NXA66 non-isolated DC/DC converter is
targeted at computing applications that
require point of load power conversion. The
NXA66 is designed to meet the precise
voltage and fast transient requirements of
today鈥檚 high performance applications such
as workstations, file servers, desktop
computers, telecommunications equipment,
adapter cards, DSP and data processing.
Employing synchronous rectification and
democratic current sharing, the NXA66 can
be used in a stand-alone configuration, or
paralleled as a building block to achieve
higher output currents or redundancy. The
current sharing specifications are met during
static conditions and transient conditions.
Patents pending
The NXA66 uses gold plated edge tab
fingers for a convenient, low impedance
interconnect scheme. This also allows
system designers to easily accommodate
future expansion in their systems. The
NXA66 has been mechanically designed to
be compatible with integral latch retention
mechanisms for improved shock and
vibration performance in the application.
The advanced democratic current sharing
technique employed by the NXA66 removes
the need for cumbersome master/slave
combinations.
[ 5 YEAR WARRANTY ]
Powered by
1
ICminer.com Electronic-Library Service CopyRight 2003

NXA66-12P3V3C 產品屬性

  • 20

  • 電源 - 板載

  • DC DC Converters

  • NXA66

  • 非隔離（POL）

  • 1

  • 10.8V

  • 13.2V

  • 3.3V

  • -

  • -

  • 20A

  • 66W

  • -

  • -

  • -

  • 模塊

  • 2.75" L x 1.38" W x 0.59" H（69.9mm x 35.1mm x 15.0mm）

  • -

  • -

  • 86%

  • 66W
