PRELIMINARY DATA SHEET

LASER DIODE

NX8560LJ-CC

EA MODULATOR INTEGRATED

1 550 nm MQW-DFB LASER DIODE MODULE

FOR 10 Gb/s APPLICATIONS

DESCRIPTION

The NX8560LJ-CC is an Electro-Absorption (EA) modulator integrated, 1 550 nm Multiple Quantum Well (MQW)

structured Distributed Feed-Back (DFB) laser diode. It is capable of transmitting up to 40 km (dispersion: 800 ps/nm)

for 10 Gb/s applications by using standard fiber.

FEATURES

鈥?Integrated electroabsorption modulator

鈥?Up to 40 km transmission 10 Gb/s (dispersion: 800 ps/nm)

鈥?Low modulation voltage

鈥?7-pin butterfly package with GPO

connector

鈥?Available for DWDM wavelengths based on ITU-T recommendations

鈥?Butterfly package with SC-UPC connector

PACKAGE DIMENSIONS (UNIT: mm, unless otherwise specified

鹵

0.2 mm)

15.24

2.54

10 MIN.

1.25

5.4

4 鈥?/div>

蠁

2.67

21.4鹵0.6

12.7鹵0.15

TOP VIEW

鈥?/div>

Cooler PD

Thermistor

MOD

8.89鹵0.13

0.9

4.55

6.0

2.54

20.83鹵0.13

26.04鹵0.13

5.08

PIN CONNECTIONS

Pin No.

Optical Fiber (SMF)

with SC Connector

Length : 1 225 MIN.

Function

Thermistor

LD DC Bias

PD Anode

PD Cathode

Cooler Anode

Cooler Cathode

8.0 鹵0.2

0.75

30.0

The information in this document is subject to change without notice. Before using this document, please confirm that

this is the latest version.

Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices

representative for availability and additional information.

Document No. PL10110EJ01V0DS (1st edition)

(Previous No. P14748EJ4V0DS00)

Date Published April 2002 CP(K)

Printed in Japan

The mark

鈥?/div>

shows major revised points.

漏

NEC Corporation 2000

漏

NEC Compound Semiconductor Devices 2002
