NUP4103FC
Four Channel ESD Array
This integrated transient voltage suppressor device (TVS) is
designed for applications requiring transient overvoltage protection. It
is intended for use in sensitive portable equipment and other
applications. Its integrated design provides very effective and reliable
protection for four (4) separate lines using only one package. These
devices are ideal for situations where board space is a premium.
Features
http://onsemi.com
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Unidirectional, Quad ESD Protection
Ultra-small Flip Chip Packaging (0.95 mm x 1.33 mm)
Compliance with IEC61000-4-2 (Level 4) Requirements
Maximum Leakage Current of 100 nA at 3.3 V
CIRCUIT DESCRIPTION
A1
C1
Benefits
B2
鈥?/div>
Protects Four Data Lines from ESD while Reducing Component
Count
鈥?/div>
Small Package Saves On PCB Real Estate
鈥?/div>
Provides Protection for ESD Industry Standards, IEC 61000, HBM
and MM
鈥?/div>
Low Leakage Capability Minimizes Power Loss in the System
Applications
A3
C3
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
ESD Protection for Portable Equipment
Cell Phones
MP3 Players
PDAs
5 PIN FLIP CHIP CSP
CASE 766AB
PLASTIC
TOP VIEW
(Bumps Down)
1 2 3
Unit
kV
30
30
16
1.6
B
B
A
A
Value
BOTTOM VIEW
(Bumps Up)
3
2 1
MAXIMUM RATINGS
(T
J
= 25擄C, unless otherwise specified)
Rating
ESD Discharge IEC61000-4-2,
- Air Discharge
- Contact Discharge
Human Body Model
Machine Model
Junction Temperature
Operating Ambient Temperature
Range
Storage Temperature Range
Symbol
V
PP
C
擄C
擄C
C
T
J
T
A
T
STG
150
-40 to +85
-55 to +150
DEVICE MARKING
擄C
ED
E = Specific Device Code
D = Month Code
ORDERING INFORMATION
Device
NUP4103FCT1
Package
Flip Chip
Shipping
3000/Tape & Reel
漏
Semiconductor Components Industries, LLC, 2003
1
June, 2003 - Rev. 0
脠
脠
Publication Order Number:
NUP4103FC/D
