NUP1301ML3T1-D Datasheet

  • NUP1301ML3T1-D

  • Low Capacitance Diode Array for ESD Protection in a Single D...

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NUP1301ML3T1
Advance Information
Low Capacitance Diode
Array for ESD Protection in
a Single Data Line
NUP1301ML3T1 is a MicroIntegration鈩?device designed to
provide protection for sensitive components from possible harmful
electrical transients; for example, ESD (electrostatic discharge).
Features
http://onsemi.com
ANODE
1
CATHODE
2
鈥?/div>
Low Capacitance (3 pf Maximum)
鈥?/div>
Single Package Integration Design
鈥?/div>
Provides ESD Protection for JEDEC Standards JESD22
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Machine Model = Class C
Human Body Model = Class 3B
Protection for IEC61000-4-2 (Level 4)
8.0 kV (Contact)
15 kV (Air)
Ensures Data Line Speed and Integrity
Fewer Components and Less Board Space
Direct the Transient to Either Positive Side or to the Ground
T1/E1 Secondary IC Protection
T3/E3 Secondary IC Protection
HDSL, IDSL Secondary IC Protection
Video Line Protection
Microcontroller Input Protection
Base Stations
I
2
C Bus Protection
Device
3
CATHODE/ANODE
3
1
2
CASE 318
SOT-23
STYLE 11
Applications
MARKING DIAGRAM
TBD M
TBD = Device Code
M = Date Code
ORDERING INFORMATION
Package
SOT-23
Shipping
3000/Tape & Reel
Rating
Reverse Voltage
Forward Current
Peak Forward Surge Current
Repetitive Peak Reverse Voltage
Average Rectified Forward
Current (Note 1)
(averaged over any 20 ms period)
Repetitive Peak Forward Current
Non-Repetitive Peak Forward Current
t = 1.0
ms
t = 1.0 ms
t = 1.0 S
Symbol
V
R
I
F
I
FM(surge)
V
RRM
I
F(AV)
Value
70
215
500
70
715
Unit
NUP1301ML3T1
Vdc
mAdc
mAdc
V
mA
MAXIMUM RATINGS
(Each Diode) (T
J
= 25擄C unless otherwise noted)
I
FRM
I
FSM
450
2.0
1.0
0.5
mA
A
1. FR-5 = 1.0

0.75

0.062 in.
This document contains information on a new product. Specifications and information
herein are subject to change without notice.
漏
Semiconductor Components Industries, LLC, 2003
1
March, 2003 - Rev. 1
Publication Order Number:
NUP1301ML3T1/D
