NUF2102UT1
Product Preview
USB Filter with ESD
Protection
This device is designed for applications requiring
Line
Termination, EMI Filtering
and
ESD Protection.
It is intended for
use in upstream USB ports, Cellular phones, Wireless equipment and
computer applications. This device offers an integrated solution in a
small package reducing PCB space and cost.
Features:
http://onsemi.com
CIRCUIT DESCRIPTION
D
(IN)
D4
Rpu
A4
V
BUS
C
Rs1
B4
D
(IN)
A1
D
(OUT)
Rs2
D
(OUT)
D1
鈥?/div>
Provides USB Line Termination, Filtering and ESD Protection
鈥?/div>
Single IC Offers Cost Savings by Replacing 3 Resistors,
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
2 Capacitors, and 5 TVs diodes
Bi鈥揹irectional EMI Filtering Prevents Noise from Entering/Leaving
the System
IEC61000鈥?鈥? ESD Protection for USB Port
Flexible Pull鈥揹own or Pull鈥搖p Line Termination to Meet USB 1.1
Low Speed and High Speed Specification
ESD Ratings: Machine Model = C
Human Body Model = 3B
C
A2鈥揇2
GND A3鈥揇3
Benefits:
鈥?/div>
MicroLeadless Package Minimizes PCB Space
鈥?/div>
Integrated Circuit Increases System Reliability versus Discrete
Component Implementation
鈥?/div>
TVS Devices Provide ESD Protection That is Better than a Discrete
Implementation because the Small IC minimizes Parasitic
Inductances
Typical Applications:
MicroLeadlesst 2020
CASE TBD
PLASTIC
鈥?/div>
USB Hubs
鈥?/div>
Computer Peripherals Using USB
MAXIMUM RATINGS
(T
A
= 25擄C)
Rating
Steady State Power
Maximum Junction Temperature
Operating Temperature Range
Storage Temperature Range
Lead Solder Temperature
(10 second duration)
Symbol
P
D
T
J(max)
T
J
T
stg
T
L
Value
225
125
鈥?5 to +125
鈥?5 to +125
260
Unit
mW
擄C
擄C
擄C
擄C
MARKING
DIAGRAM
4 3 2
1
A
B
C
D
TBD D
(Top Side)
(Pad Side)
TBD = Specific Device Code
D
= Date Code
ORDERING INFORMATION
Device
NUF2102UT1
Package
MicroLeadless
2020
Shipping
3000/Tape & Reel
This document contains information on a product under development. ON Semiconductor
reserves the right to change or discontinue this product without notice.
漏
Semiconductor Components Industries, LLC, 2002
1
May, 2002 鈥?Rev. 0
Publication Order Number:
NUF2102UT1/D
