NUF2101W1T1-D Datasheet

  • NUF2101W1T1-D

  • USB 1.1 DownStream EMI Filter with ESD Protection

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NUF2101W1T1
Advance Information
USB Filter with ESD
Protection
This device is designed for applications requiring
Line
Termination, EMI Filtering
and
ESD Protection.
It is intended for
use in downstream USB 1.1 ports, Cellular phones, Wireless
equipment and computer applications. This device offers an integrated
solution in a small package (SC-88, Case 419B) reducing PCB space
and cost.
Features:
http://onsemi.com
SCHEMATIC
D+
OUT
1
15 k
V
BUS
2
15 k
D-
OUT
3
D-
IN
4
5
R
S
D+
IN
6
鈥?/div>
Provides USB Line Termination, Filtering and ESD Protection
鈥?/div>
Single IC Offers Cost Savings by Replacing 4 Resistors,
2 Capacitors, and 5 TVs diodes
鈥?/div>
Bi-directional EMI Filtering Prevents Noise from Entering/Leaving
the System
鈥?/div>
IEC61000-4-2 ESD Protection for USB Port
鈥?/div>
ESD Ratings: Machine Model = C
ESD Ratings:
Human Body Model = 3B
Benefits:
鈥?/div>
SC-88 Package Minimizes PCB Space
鈥?/div>
Integrated Circuit Increases System Reliability versus Discrete
Component Implementation
鈥?/div>
TVs Devices Provide ESD Protection That is Better than a Discrete
Implementation because the Small IC minimizes Parasitic
Inductances
Typical Applications:
6
5
4
1
2
3
SC-88
CASE 419B
PLASTIC
鈥?/div>
USB Hubs
鈥?/div>
Computer Motherboards
MAXIMUM RATINGS
(T
A
= 25擄C)
Rating
Steady State Power
Maximum Junction Temperature
Operating Temperature Range
Storage Temperature Range
Lead Solder Temperature
(10 second duration)
Symbol
P
D
T
J(max)
T
J
T
stg
T
L
Value
225
125
-55 to +125
-55 to +125
260
Unit
mW
擄C
擄C
擄C
擄C
PINOUT AND MARKING DIAGRAM
1
D+
OUT
GND
3
D-
OUT
TBD
d
TBD d
2
6
5
4
D+
IN
V
BUS
D-
IN
= Specific Device Code
= Date Code
This document contains information on a new product. Specifications and information
herein are subject to change without notice.
ORDERING INFORMATION
Device
NUF2101W1T1
Package
SC-88
Shipping
3000/Tape & Reel
漏
Semiconductor Components Industries, LLC, 2003
1
February, 2003 - Rev. 0
Publication Order Number:
NUF2101W1T1/D
