NUD3150/D Datasheet

  • NUD3150/D

  • Integrated Relay Inductive Load Driver

  • 82.56KB

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

NUD3105
Integrated Relay,
Inductive Load Driver
This device is used to switch inductive loads such as relays,
solenoids incandescent lamps , and small DC motors without the need
of a free鈭抴heeling diode. The device integrates all necessary items
such as the MOSFET switch, ESD protection, and Zener clamps. It
accepts logic level inputs thus allowing it to be driven by a large
variety of devices including logic gates, inverters, and
microcontrollers.
Features
http://onsemi.com
鈥?/div>
Provides a Robust Driver Interface Between D.C. Relay Coil and
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Sensitive Logic Circuits
Optimized to Switch Relays from 3.0 V to 5.0 V Rail
Capable of Driving Relay Coils Rated up to 2.5 W at 5.0 V
Internal Zener Eliminates the Need of Free鈭扺heeling Diode
Internal Zener Clamp Routes Induced Current to Ground for Quieter
Systems Operation
Low V
DS(ON)
Reduces System Current Drain
RELAY/INDUCTIVE
LOAD DRIVER
SILICON SMALLBLOCK]
0.5 Ampere, 8.0 V Clamp
MARKING
DIAGRAM
3
SOT鈭?3
TO鈭?36
CASE 318
2
JW4D
1
Typical Applications
鈥?/div>
Telecom: Line Cards, Modems, Answering Machines, FAX
鈥?/div>
Computers and Office: Photocopiers, Printers, Desktop Computers
鈥?/div>
Consumer: TVs and VCRs, Stereo Receivers, CD Players, Cassette
Recorders
鈥?/div>
Industrial:Small Appliances, Security Systems, Automated Test
Equipment, Garage Door Openers
鈥?/div>
Automotive: 5.0 V Driven Relays, Motor Controls, Power Latches,
Lamp Drivers
Gate (1)
JW4
D
= Specific Device Code
= Date Code
INTERNAL CIRCUIT DIAGRAM
Drain (3)
1.0 k
300 k
Source (2)
ORDERING INFORMATION
Device
NUD3105LT1
Package
SOT鈭?3
Shipping
鈥?/div>
3000 Units/Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2004
1
January, 2004 鈭?Rev. 3
Publication Order Number:
NUD3105/D
